Produce name: Fresh Water Generator

      Daily capacity: 1-50T performance curve shows the capacity of 9 standard AFGU-1 single-effect fresh water generator at different jacket water temperatures.
The maximum flow and corresponding jacket water temperature difference △t℃ have been shown in the technical data of heat exchanger; the minimum flow and corresponding jacket water temperature difference △t℃ have been specified for each upper and lower capacity curve. When the sea water temperature is 30℃, capacity has been calculated; When the sea water temperature is 20℃, capacity will be 10% higher.
Fresh Water Generator Data
Outline Dimension

AFGU
单位(mm)
1E
1S(E)
1.5
7
15
25
36
50
长(L)
Length
750
1100
1860
2310
2130
2850
Width
600
900
1070
1300
1455
1600
Height
1150
1450
1670
1900
1970
2100
Pull out cond.
700
1400
1700
1900
2300
2500
Pull out heat
-
-
1110
1450
1705
1800
Weight empty. Water
230
530
800
1450
1650
2000
Weight full. Water
290
930
1600
2300
3000
4000
Weight work. Water
250
600
900
1700
2000
2500
External con. Condenser in/out
32
50
65/100
100
100
125
Ejector p.com
40/32
50
50
65
65
80
Ejector water brine discharge
-
-
65
65
65
80
Freshwater outlet
15
15
15
25
25
25
Emptying heat exchanger
-
-
25
25
25
25
Supply power
5.0
5.7
6.5/7.5
8.0/12.5
8.0/13.8
8.2

On-board Data


Type
Data
E1.5
E7
S15
    E15
S25

    E25
S36
    E36
S50
Net weight(kg)
310
630
800
1450
1650
2000
Packing weight
gross weight
400
750
1000
1600
1800
2350
Un-packing weight
360
680
890
1500
1730
2080
Volume
0.6
1.5
2.4
4.5
6.0
7.1
